VISA-Counter

SITEC VISA 2013 Schaltfenster, für Konsulate, Botschaften und Amtsgebäude

Construction and Implementation

This complete unit is primarily used as a VISA-counter in consulates, embassies, and government buildings and has been developed according to the specifications of the BBR (Federal Office for Building and Regional Planning).

The VISA-counter is designed for indoor use and is intended for installation in a wall. The counter is fully ready for installation and equipped with an installation frame, glazing, counter element, and transfer tray. Of course, we also manufacture accessories for the counter element, such as DELTA 2.0 intercom system, counter system, shelves, and partition walls.

VISA 2013 Counter Window

Bullet resistance class FB 4 / BR 4 – NS with test certificate for the entire element in FB 4, fully ready for installation, consisting of:

  • Installation frame, glazing BR 4 – NS
  • Tabletops made of multiplex birch, plastic-coated with visible, clear lacquered edges
  • Transfer tray P7032 FB 4, stainless steel execution
  • Lighting element
SITEC VISA 2013 Schaltfenster, mit Sprechanlage, für Konsulate, Botschaften und Amtsgebäude

AREAS OF APPLICATION

Embassies, consulates

INSTALLATION

In a dry wall

Wall opening

W x H x D = 1,170 x 1,610 x variable mm

Throughput size

W x H x D = 380 x 85 x 274 mm

Execution

Transfer tray with V2A stainless steel cover, multiplex birch tabletop, all visible parts lacquered in Sikkens 3031 grey

Bullet resistance class

FB 4, glass in BR 4 – NS (DIN EN 1522)
